Nissan 26296-89947 Bulb

To access the front parking/turn signal and side marker lights, detach the plastic inner fender liner at the front edge and pull it back to reach the bulbs; for 2010 and earlier models, the side marker bulb can be accessed from under the hood. Turn the bulb sockets counterclockwise and pull them out of the housing, then remove the bulb from the bulb holder, with installation being the reverse of removal. For the rear turn signal, brake, tail, side marker, and back-up lights, remove the rear trim panel from the trunk interior by taking out the plastic fasteners, then unclip the trunk interior liner to access the rear taillight assembly. Remove the nuts from the studs, take out the taillight assembly by prying it rearward, twist the bulb holder counterclockwise to pull it from the housing, and remove the bulb from the holder, with installation reversing the removal steps. For fog lights, detach the plastic inner fender liner at the front edge, disconnect the electrical connector from the bulb holder, turn the bulb holder counterclockwise to pull it out, and reinstall by reversing the steps. To replace the license plate light, loosen the trunk lid finish panel, twist the bulb socket counterclockwise to remove it, pull the bulb out to replace it, and reinstall by reversing the steps. For the high-mounted brake light, push the housing to the rear, release the front mounting tabs, slide it to the front to release the rear tabs, lift the housing, twist the bulb socket counterclockwise to remove it, pull the bulb out to replace it, and reinstall by reversing the steps. Interior light bulbs are replaced by carefully prying off the lens with a small screwdriver or trim tool, pulling the bulb straight out of its socket, replacing it, and snapping the lens back in place; for the trunk light bulb, release the tab on the side of the lens, pivot it open, and replace the bulb as described. Instrument cluster illumination is contained within the cluster, and if there is a problem with any of its components, the entire cluster should be replaced.

Tiny bulbs serve as turn/park functions in the round bulb of the headlight housing but large bulbs function as side marker lights. The liner gets access after uninstalling the mounting fasteners to expose the fender section. After twisting the side marker or turn signal light bulb holder counterclockwise behind the headlight housing you can pull out the bulb straight from the socket by reversing these steps for installation. To replace the taillights separate the liftgate first then remove both inboard fasteners securing the housing and carefully place the projected pins through body holes while installing. The bulb socket detachment from the housing allows replacement of bulbs after turning the bulb holder counterclockwise. To replace the license plate light start by unsnapping its housing from the bumper then taking out the bulb holder followed by bulb replacement. Proceed as follows to reach and maintain the high-mounted brake light: access the mounting nuts behind interior roof plastic covers through the tailgate opening then pull out the assembly while twisting out bulb holders for new bulb installation. The instrument cluster lights which belong to the circuit board feature built-in components that cannot be replaced. You must use a small screwdriver to pry off the dome light and map light lenses for interior bulb replacement. After disconnecting the electrical connector which operates from under the fog light housing's rear section rotate the bulb counterclockwise to extract it while twisting the new bulb counterclockwise into the socket which requires special care because touching the bulb surface with hands will lead to overheating and shortening its lifespan although cleaning the touched bulb with rubbing alcohol helps.

To replace exterior lights begin with the front parking and turn signal lights removes the head light housing, rotate the bulb socket anti clock wise to pull it, remove bulb from the holder, and the procedure of installation is reversed. For rear turn signal, brake, tail, side marker, and back-up lights on hatchback models, the rear access panels must be removed having two nuts at the studs, which must be unscrewed and after that the assembly must be pulled straight back; the bulb holder must be twisted in anticlockewise direction in order to unlock it from its place and then the bulb has to be removed, also in reverse order. For models of sedans, first, take out the trunk inner trim, then by twisting it clockwise the bulb can be detached, and then reinstall it in a reverse manner. To replace the fog light bulb you will have to remove the inner fender splash shield partially to have access to it, then you have to unscrew the electrical connector, rotate the bulb holder anti-clockwise in order to pull it out, and finally reuse in the reverse method. For assembly removal and installation of fenders, partly remove the inner fender splash shield and lower cover, disconnect the electrical connector, unlock the pawl, unscrew the mounting bolt of fender finish panel and secure back in a reversed manner. On license plate lights on the hatches, compression has to be done on the latching pawl to unlock it, then the fixture can be pulled down and bulb removed, followed by an installation process in the reverse manner. For sedan models, first, to remove the nuts, homeowners have to eliminate the trunk lid trim finisher, to follow, get rid of the license plate fixture, next twist the bulb socket in the counter clockwise direction to pull it out and finally, to get rid of the bulb and reinstall everything in the opposite manner. The high-mounted brake light assembly on hatchback models involved the removal of the lift gate trim panel and this makes it easy to access the electrical connector that has to be disconnected, to get at the retaining nuts which also have to be removed and for the replacement of the high-mounted brake light assembly the above sequences have to be followed in reverse, sedan models with a rear air spoiler, requires the removal of the spoiler then the high-mounted brake light trim followed For those sedans that do not have the feature of rear air spoiler, then you can proceed to lose the rear parcel shelf, the mounting screws and the assembly, but install them in the reverse order. If you want to replace the bulb and the fixture is located inside the trunk, the steps are simply as follows; unscrew the fixture anti-clockwise, take out the bulb and replace in a similar manner. Interior light bulbs are removed by popping off the lens with a flat head screwdriver or trim stick and gently pulling the bulb out with fingers and then inserting in the reverse way. For illumination of instruments like the speedometer, odometer, and other gadgets, if there is an issue with any of the gadgets, change the whole cluster as it forms a single unit.

To access the exterior lights, locate the bulb sockets in the headlight housing from the engine compartment. For SE-R models, remove the air filter resonator to reach the left side bulbs.
