How to disconnect the cable from the negative terminal of the battery and remove the instrument cluster on Nissan Altima?

Disconnect the cable from the negative terminal of the battery. Remove the instrument cluster bezel. Remove the retaining screws and pull the cluster out. Unplug the electrical connectors and remove the cluster from the vehicle. Installation is the reverse of removal. Reconnect the battery and perform the necessary re-learn procedures.

How to remove the instrument cluster on the Nissan Maxima?

This operation is problematic for homeworkers because the sequence of disassembly is intricate and includes many electrical connections. Lead with the removal of the cable on the negative end of the battery. Unbolt the center console and the steering column trim, next is the instrument cluster cover, and then the instrument cluster. Remove the trim panels of the dashboard and the knobs and buttons of the radio together with the heater/air conditioner. For the models up to 2003, both the kick panels for each side, the trims around the windshield posts, and the passenger airbag have to be detached by the removal of screws. Open the upper bolts of the instrument panel by prying up the defroster grilles and then retract all the fasteners and electric connections that are present on the panel and then, the instrument panel should be pulled out of the vehicle. Disengage all the wiring harness clips and connectors on the instrument panel reinforcement beam and pull out the bolts and angle the beam out. For models from 2004 and later, there are stepper motors on the rear of the center trim panels, harnesses should be disconnected, screws should be unscrewed on the navigation control unit, center stack should be removed. Without the instrument cluster and passenger airbag, you next step would be to take out the ignition switch trim cover and the driver side knee bolster. Separate the tilt switch, and take off the front door trim welting and front door scuff plates as well as the front door pillar side trim. Lift up the lower dash trim panels and the steering column covers, disconnect wiring connector, and loose steering column by taking out the pinch bolt. Last, eliminate the instrument mounting bolts, then disengage any remaining electrical connections, and finally, expel the instrument panel out from the car going through the procedures in the reversal process.

Is removing the instrument cluster on the Nissan Murano definitely a two-man job?

This is definitely a two-man job. Even stripped of all its components, the instrument panel, or dashboard, is fairly heavy; do NOT attempt to lift it out of the vehicle by yourself. Begin by disconnecting the cable from the negative terminal of the battery. Move the front seats as far back as they will go, as removing the seats will provide more working room. Next, remove the center console, steering wheel, steering column covers, and all dashboard trim panels. Proceed to remove all dashboard-mounted speakers, the instrument cluster, the heater and air conditioning control unit, the audio unit, and the display screen from behind the center vent unit. Disconnect the wiring from the passenger's airbag module and remove the module's mounting bolt, noting that all electrical connectors for airbag harnesses are bright yellow. Clearly label and disconnect all electrical connectors in the dashboard area, detaching all wiring harnesses from the dash, while keeping in mind that you might not be able to reach every harness clip. Remove all eight instrument panel mounting screws, which include screws located behind the instrument cluster, at both ends of the instrument panel, in the glove box area, and on both sides of the tunnel. With the help of an assistant, lift the instrument panel back just far enough to access and disconnect any remaining wiring harnesses or other components, then carefully remove the instrument panel through the passenger's door opening. Installation is the reverse of removal, and remember to reconnect the battery and perform the necessary re-learn procedures.

Genuine Nissan Instrument Cluster

Speedometer Instrument Cluster

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

2138 Instrument Clusters found

View related parts
Nissan Front Combination Meter Cover
Part Number: 24813-EA405
$83.17 MSRP: $128.15
You Save: $44.98 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover-Front,Combination Meter; Cover, Lens
- Position: Front
Fits the following Nissan Models:
- Frontier | 2005-2021 | Desert Runner, LE, Off-Road, PRO-4X, S, SE, SL, SV, XE | 4 Cyl 2.5 L GAS, 4 Cyl 2.5L, 6 Cyl 3.8 L GAS, 6 Cyl 4.0 L FLEX, 6 Cyl 4.0 L GAS, 6 Cyl 4.0L
- Pathfinder | 2005-2012 | LE, S, SE, SE Off-Road, Silver Edition, SV, XE | 6 Cyl 4.0L, 8 Cyl 5.6L
- Xterra | 2005-2015 | Base Camp, Off-Road, PRO-4X, S, SE, X | 6 Cyl 4.0L
View More
View related parts
Nissan Cover-Front, Combination Meter
Part Number: 24813-7FR0A
$55.80 MSRP: $83.91
You Save: $28.11 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover-Front,Combination Meter; Lens
- Position: Front
Fits the following Nissan Models:
- Rogue | 2016-2020 | S, SL, SL Hybrid, SV, SV Hybrid, SV Premium | 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 2.5 L GAS, 4 Cyl 2.5L
- Rogue Sport | 2017-2022 | S, SL, SV | 4 Cyl 2.0 L GAS, 4 Cyl 2.0L
View related parts
Nissan Instrument Combination
Part Number: 24810-9HP0A
$632.49 MSRP: $974.56
You Save: $342.07 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Combination Meter Assy-Instrument
Fits the following Nissan Models:
- Altima | 2014-2016 | Base, Entry, S, S PDS, SL, SV, SV Navigation, Tech | 4 Cyl 2.5L, 6 Cyl 3.5L
View related parts
Nissan Instrument Combination Meter Assembly
Part Number: 24810-9FV1A
$1069.65 MSRP: $1648.15
You Save: $578.50 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Combination Meter Assy-Instrument; Cluster Assembly, Instrument Cluster
Fits the following Nissan Models:
- Titan | 2022-2023 | PRO-4X, Platinum Reserve, S, SV | 8 Cyl 5.6 L GAS
View related parts
Nissan Speedometer Instrument Cluster
Part Number: 24810-9PM0A
$717.51 MSRP: $1105.56
You Save: $388.05 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Combination Meter Assy-Instrument; Cluster Assembly, Instrument Cluster
- Replaces: 24810-9PJ0A
Fits the following Nissan Models:
- Pathfinder | 2016-2020 | Platinum, S, SL, SV | 6 Cyl 3.5 L GAS, 6 Cyl 3.5L
View related parts
Nissan Lid-Cluster
Part Number: 68240-4RA0A
$146.59 MSRP: $225.87
You Save: $79.28 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Bezel
Fits the following Nissan Models:
- Maxima | 2016-2023 | 40th Anniversary Edition, Platinum, Platinum Reserve, S, SL, SR, SV | 6 Cyl 3.5 L GAS, 6 Cyl 3.5L
View related parts
Nissan Lid Cluster BRN
Part Number: 68240-1LA0B
$299.01 MSRP: $460.73
You Save: $161.72 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lid-Cluster; Cluster Bezel
Fits the following Nissan Models:
- Armada | 2017-2020 | Platinum, Platinum CP, Platinum Reserve, SL, SV | 8 Cyl 5.6 L GAS, 8 Cyl 5.6L
View related parts
Nissan Instrument Comb
Part Number: 24810-6RR2A
$733.56 MSRP: $1130.29
You Save: $396.73 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly, Instrument Cluster
- Replaces: 24810-6RR0A
Fits the following Nissan Models:
- Rogue | 2021 | Platinum, S, SL, SV | 3 Cyl 1.5 L GAS, 4 Cyl 2.5 L GAS
View related parts
Nissan Lid-Cluster
Part Number: 68240-3KA0A
$101.13 MSRP: $155.82
You Save: $54.69 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Bezel
Fits the following Nissan Models:
- Pathfinder | 2013-2020 | Platinum, Platinum Hybrid, S, SL, SL Hybrid, SV, SV Hybrid | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 2.5L, 6 Cyl 3.5 L GAS, 6 Cyl 3.5L
View related parts
Nissan Front Combination Meter Cover
Part Number: 24813-5RD0A
$22.60 MSRP: $33.98
You Save: $11.38 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover - Front Meter; Cluster Lens, Lens
- Position: Front
Fits the following Nissan Models:
- Kicks | 2018-2024 | SR, SR PLUS, SV | 4 Cyl 1.6 L GAS, 4 Cyl 1.6L
- Versa | 2020-2025 | SR, SV | 4 Cyl 1.6 L GAS
View related parts
Nissan INSTRUMENT-COMB
Part Number: 24820-6JC9D
$1318.05 MSRP: $2030.89
You Save: $712.84 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Replaces: 24820-6JC5A, 24820-6JC5D, 24820-6JC5B
Fits the following Nissan Models:
- Armada | 2020 | Platinum, Platinum Reserve, SL, SV | 8 Cyl 5.6 L GAS
View related parts
Nissan Instrument Speedometer Cluster
Part Number: 24810-ZG105
$809.20 MSRP: $1246.84
You Save: $437.64 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Combination Meter Assy-Instrument; Cluster Assembly
- Replaces: 24810-ZG51E
Fits the following Nissan Models:
- Sentra | 2004-2006 | 1.8S, GXE | 4 Cyl 1.8L
View related parts
Nissan Lid Cluster BRN
Part Number: 68240-EZ01A
$169.91 MSRP: $261.80
You Save: $91.89 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lid-Cluster; Cluster Bezel
Fits the following Nissan Models:
- Titan | 2016-2024 | PRO-4X, Platinum, Platinum Reserve, S, SL, SV, SV/Comf | 8 Cyl 5.0 L DIESEL, 8 Cyl 5.0L Diesel, 8 Cyl 5.6 L GAS, 8 Cyl 5.6L
View related parts
Nissan Lid Cluster BRN
Part Number: 68240-1LA0A
$263.34 MSRP: $405.76
You Save: $142.42 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lid-Cluster; Cluster Bezel
Fits the following Nissan Models:
- Armada | 2017-2020 | Platinum, Platinum CP, Platinum Reserve, SL, SV | 8 Cyl 5.6 L GAS, 8 Cyl 5.6L
View related parts
Nissan Speedometer Instrument Cluster
Part Number: 24810-ZS40E
$321.59 MSRP: $495.51
You Save: $173.92 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Combination Meter Assy-Instrument
- Replaces: 24810-ZP51B
Fits the following Nissan Models:
- Frontier | 2006-2010 | SE, SV | 6 Cyl 4.0L
View related parts
Nissan Instrument Pad
Part Number: 68210-3TA0A
$333.89 MSRP: $514.47
You Save: $180.58 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Assy-Instrument; Cluster Bezel
Fits the following Nissan Models:
- Altima | 2013-2018 | 25SL/Moon Roof, Base, Entry, S, S PDS, SL, SR, SV, SV Navigation, Tech | 4 Cyl 2.5L, 6 Cyl 3.5L
View related parts
Nissan Instrument Combination Meter Assembly
Part Number: 24810-4RA4A
$907.33 MSRP: $1398.04
You Save: $490.71 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Combination Meter Assy-Instrument; Instrument Cluster
Fits the following Nissan Models:
- Maxima | 2020-2022 | Platinum, Platinum Reserve, S, SL, SR, SV | 6 Cyl 3.5 L GAS
View related parts
Nissan Instrument Cluster Speedometer Assembly
Part Number: 24820-3WS3A
$1097.88 MSRP: $1691.65
You Save: $593.77 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Speedometer Assy; Cluster Assembly, Instrument Cluster
- Replaces: 24820-1JA2D, 24820-1JA3D
Fits the following Nissan Models:
- Quest | 2011-2017 | S, SL, SV | 6 Cyl 3.5L
View related parts
Nissan Front Combination Meter Cover
Part Number: 24813-EA000
$65.47 MSRP: $100.87
You Save: $35.40 (36%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cover-Front,Combination Meter; Cover, Lens
- Position: Front
Fits the following Nissan Models:
- Frontier | 2020-2021, 2005-2009 | LE, Nismo Off-Road, Off-Road, PRO-4X, S, SE, SV, XE | 4 Cyl 2.5 L GAS, 4 Cyl 2.5L, 6 Cyl 3.8 L GAS, 6 Cyl 4.0 L GAS, 6 Cyl 4.0L
- Xterra | 2005-2011 | Base Camp, Off-Road, PRO-4X, S, SE, X | 6 Cyl 4.0L
View related parts
Nissan Cover-Front, Combination Meter
Part Number: 24813-4BA0A
$37.44 MSRP: $56.31
You Save: $18.87 (34%)
Product Specifications
- Other Name: Cover-Front,Combination Meter; Lens
- Position: Front
Fits the following Nissan Models:
- Rogue | 2014-2019 | S, SL, SL/Premium, SV, SV Premium | 4 Cyl 2.0L, 4 Cyl 2.5L

| Page 1 of 107 |Next >

1-20 of 2138 Results

About Nissan Instrument Cluster

A Nissan instrument cluster diligently works to serve the driver information on the current status of the vehicle, measuring a several different things. The whole cluster itself has one or several connections at the back of it which plug into the ECU, so that it can receive and display the information like your gas level, speed and the temperature of your engine. Whenever it is operating like a top, the cluster shows you all the tidbits and car vitals you need to know, so you can continue to drive it safely.
Most modern day instrument clusters are at least part digital, and are situated right where the driver sits so they can see everything clearly. Now if your instrument cluster is all connected and powered up, and only a few or none of the gauges are operational, your cluster may be in need of replacement as soon as possible. It is not necessary to take any driving risks with a shoddy instrument cluster that doesn't fully work like it should. Getting yourself a speeding ticket, running out of fuel and overheating your motor are all things which can result from a bad cluster.
Thanks for shopping at NissanPartsDeal.com. We are you first choice when it comes to genuine Nissan parts and accessories. The simple and easy-to-use website page design will guide you to the part you are looking for in seconds. We only sell 100% genuine parts, and all parts here are brand new and made in a high specification. We offer you a surprisingly low price, and it is even much lower than wholesale. Do not hesitate to contact our customer service via live chat or phone, and they will help you with any problem you may meet.

Nissan Instrument Cluster Parts Questions & Experts Answers

Speedometer Instrument Cluster
24810-JA00A
Q: How to disconnect the cable from the negative terminal of the battery and remove the instrument cluster on Nissan Altima?
A:
Disconnect the cable from the negative terminal of the battery. Remove the instrument cluster bezel. Remove the retaining screws and pull the cluster out. Unplug the electrical connectors and remove the cluster from the vehicle. Installation is the reverse of removal. Reconnect the battery and perform the necessary re-learn procedures.
Speedometer Assembly
24820-0L700
Q: How to remove the instrument cluster on the Nissan Maxima?
A:
This operation is problematic for homeworkers because the sequence of disassembly is intricate and includes many electrical connections. Lead with the removal of the cable on the negative end of the battery. Unbolt the center console and the steering column trim, next is the instrument cluster cover, and then the instrument cluster. Remove the trim panels of the dashboard and the knobs and buttons of the radio together with the heater/air conditioner. For the models up to 2003, both the kick panels for each side, the trims around the windshield posts, and the passenger airbag have to be detached by the removal of screws. Open the upper bolts of the instrument panel by prying up the defroster grilles and then retract all the fasteners and electric connections that are present on the panel and then, the instrument panel should be pulled out of the vehicle. Disengage all the wiring harness clips and connectors on the instrument panel reinforcement beam and pull out the bolts and angle the beam out. For models from 2004 and later, there are stepper motors on the rear of the center trim panels, harnesses should be disconnected, screws should be unscrewed on the navigation control unit, center stack should be removed. Without the instrument cluster and passenger airbag, you next step would be to take out the ignition switch trim cover and the driver side knee bolster. Separate the tilt switch, and take off the front door trim welting and front door scuff plates as well as the front door pillar side trim. Lift up the lower dash trim panels and the steering column covers, disconnect wiring connector, and loose steering column by taking out the pinch bolt. Last, eliminate the instrument mounting bolts, then disengage any remaining electrical connections, and finally, expel the instrument panel out from the car going through the procedures in the reversal process.
Speedometer Assembly
24820-1SX5A
Q: Is removing the instrument cluster on the Nissan Murano definitely a two-man job?
A:
This is definitely a two-man job. Even stripped of all its components, the instrument panel, or dashboard, is fairly heavy; do NOT attempt to lift it out of the vehicle by yourself. Begin by disconnecting the cable from the negative terminal of the battery. Move the front seats as far back as they will go, as removing the seats will provide more working room. Next, remove the center console, steering wheel, steering column covers, and all dashboard trim panels. Proceed to remove all dashboard-mounted speakers, the instrument cluster, the heater and air conditioning control unit, the audio unit, and the display screen from behind the center vent unit. Disconnect the wiring from the passenger's airbag module and remove the module's mounting bolt, noting that all electrical connectors for airbag harnesses are bright yellow. Clearly label and disconnect all electrical connectors in the dashboard area, detaching all wiring harnesses from the dash, while keeping in mind that you might not be able to reach every harness clip. Remove all eight instrument panel mounting screws, which include screws located behind the instrument cluster, at both ends of the instrument panel, in the glove box area, and on both sides of the tunnel. With the help of an assistant, lift the instrument panel back just far enough to access and disconnect any remaining wiring harnesses or other components, then carefully remove the instrument panel through the passenger's door opening. Installation is the reverse of removal, and remember to reconnect the battery and perform the necessary re-learn procedures.
